Flash Wall 2880

Order no.: 58975d
Power consumption: 1800 W

As an attractive and vibrant element this modular interactive water wall is suitable for the use in public areas, such as Shopping malls, office complexes and theme parks. The unique arrangement of the nozzles allows for an extremely dense curtain of water, which guarantees high visibility.
This water curtain creates graphics, designs, characters, etc., which can be represented through the use of a fast reacting valve technology. Thereby the OASE Flash Wall allows for almost unlimited opportunities to convey (advertising) messages. In optional combination with an SMS interface it can be also used as an interactive communication platform.

Technical details
• For fresh water, max 50 µm particles allowed
• 110 – 240V 50/60 Hz power supply
• Transformers can be at the flash wall or in separate area control cabinet, depending on environment conditions
• Max. height recommended 10 m (under zero wind condition)
• Nozzle diameter 4.6 mm
• Individually configured water inlet and water outlet

Product characteristics at a glance
• Modular flash wall system – curved / straight (Ø 3, 4, 5, 6, 7 or 8 [m] are possible)
• Close packed nozzle/ valve arrangement for dense water curtain guaranteeing high resolution
• Ideally suited for rear projection for videos and laser graphics
• Precise valve control via DMX/CAN
• Accurately defined text and graphics displays due to fast reacting valve technology
• Optional: LED RGB Illumination
• Optional: SMS interface for the display of personal text messages

Warranty: 1 year


Order no.: 58975d
Amount of the valves: 256
Distance between the nozzles: 11.25mm
Rated voltage: 24V/DC
Power consumption: 1800 W
Water consumption: 128 l/min
Material: stainless steel / POM
Weight dry: 140kg
Weight filled with water: 168kg


Download Documents

Brochure : Flash Wall 2880
