Underwater LED Driver /DMX/02

Order no.: 50720
Dimensions: 153Lx130Wx89H mm

SKU: 50720 Category: Tag:

The Underwater LED Driver / DMX / 02 is the driver for LED-RGB(W) light: Up to 4 lights can be controlled individually.
The LED-RGB (W) lights in combination with the Underwater LED Driver can be controlled via DMX/RDM. They send back information like running time to the electrical controller. These status signals enable remote diagnosis and remote maintenance. This is the service concept for the future. Due to its robust construction, the whole system is suitable for fresh water, pool water and sea water applications (for definition see page 246).The Underwater LED Control is equipped with one DMX-box with one meter cable and one powerbox with one meter cable (for power supply). The waterproof plug-in connection system eliminates

Product characteristics at a glance
• Controller for LED-light
• Underwater LED control for:
ProfiLux LED 110/DMX/02 56267
ProfiPlane LED 110/DMX/02 56298
ProfiLux LED 320/DMX/02 50717
ProfiRing LED 320/DMX/02 50718
ProfiPlane LED 320/DMX/02 50719
ProfiLux LED Spot 1500/DMX/02 56388
ProfiLux LED Flood 1500/DMX/02 56391
• Input: 1 x 24 V/DC; 1 x DMX-RDM
• Up to 4 LED Spots
• Individually controllable via DMX/RDM
• IP 68 protection
• With patented underwater connection technologythe need for manual wiring of the individual strands.

Warranty: 1 year


Order no.: 50720
Dimensions: 153L x 130W x 89H mm
Slot: 4 x Hybrid (Data + Power)
Max. secondary power: 180 w
Protection class: IP 68
DMX Connection 1.0 m with: Box
Power Connection 1.0 m with: Box
Weight: 2.90 kg


Download Documents

Brochure: Underwater LED Driver /DMX/02
