FiltoMatic CWS 25000

36,460,000

Order no.: 50925
Power consumption: 27 W

Product characteristics
UVC with integrated stainless steel reflector for even more effective sterilisation
Suitable for ponds up to 25 m³
Intelligent control system adjusts the filtration capacity to the seasonal requirements of the pond
Up to 40% power savings thanks to UVC unit with patented self-cleaning that is activated as needed; also includes oxygen enrichment
Incl. OASE Clear Water Guarantee
Virtually invisible, the filter device can be buried to 70 % of the device height
Cleaning effort is reduced thanks to automatic sludge discharge of the filter
Convenient cleaning of the filter foams
Long service life and high quality filter sponges offer the best conditions for the filter biology
Less string algae through continuous removal of phosphates and nutrients
Interval cleaning, UVC and pump function can also be controlled manually
Special space saving filter design
Determination of the specific replacement requirement of the bulb thanks to UVC operating hours meter
Easy installation, low maintenance and user friendly
Available in three different sizes

Warranty: 1 year

Specifications

Order no.: 50925
Dimensions(LxWxH): 380x580x720 mm
Rated voltage: 230 V / 50 Hz
Power consumption: 27 W
Power consumption cleaning: 54 W
Power cable length: 10 m
Net weight: 13,92 kg
UVC power: 24 W
Number of purple filter foams: 4 ST
Number of red filter foams: 2 ST
[/ Col] [Col span = “1/2”] Temperature display: Digital
UVC operating hours meter: 8000 h
Connection inlet: 38 mm
Connection inlet: 1 1/2″
Connections, outlet: DN 75
Connections, sludge discharge: DN 40
Min. flow rate: 3500 l/h
Max. flow rate: 6000 l/h
Suitable for ponds up to max.: 25 m3
Suitable for ponds with fish stock: 12,5 m3
Suitable for ponds with koi: 6,5 m3



Pictures

Download Documents

Brochure: FiltoMatic CWS 25000

Manual: FiltoMatic CWS 25000
